Design quartz clock hands
Design quartz clock hands for the Clockworks battery operated movements. These will fit all the battery movements sold by Clockworks. The minute hand has an oblong mounting hole and the hour hand has a round one.
measuring the minute hand is done from the mounting hole to the end. The hour hand will just come shorter proportionately and comes with the minute hand.
Battery Quartz Clock Hands - Quartz clock hands in black and gold. Please choose the length by the minute hand only. - Clockworks
These are sold as a pair with both hour and minute hands. Of course, styles vary depending on length.
Quartz Clock Hands
These are quartz Clock Hands that will fit any battery movement we offer. There are two types of quartz hands in the world. One is the China standard and one is the American standard. The China way of using the hands is with round holes in both the hour and minute hands.Comparatively, the American style has an oblong mounting hole in the minute hand and a round hole for the hour hand that fits what is known as an "I" shaft. All of the hands that we offer fit "I" shaft movements only. In other words all of them will fit the quartz movements that we sell.
Quartz clock hand compatibility
When replacing a quartz clock movement, the old hands may fit the new movement just fine. However, if there is an oblong hole in the minute hand, chances are good that it will fit.The hour hand will fit the new quartz movement either way. To clarify, it is the minute hand (the longer of the two hands) that is a concern. In any event, if in doubt, it is best to order new hands for the new movement upon checking out. This way it will be all set and you will have everything you need for a smooth movement swap out.
Measuring and Ordering New Hands
Quartz clock hands come together as a set, but you only measure the minute hand when replacing them. Measure it, the long hand, from the mounting hole to the tip. The shorter hand, the hour hand, comes with the minute hand and is proportionally smaller.For larger dials that are more than 10 inches wide, see our High Torque movement and Hands section. As for Second hands, they will fit the high torque clock movements, however they do not come in long lengths like the minute hands do.
Mounting Quartz Clock Hands
Mounting quartz clock hands is easy. First put on the hour hand, with it’s round hole. As a friction fit, just push it on. The minute hand, with its oblong mounting hole, and goes on next.Fit it onto the “I” on the top of the shaft. To tighten the hands use the nut with a hole if using a second hand. However, use the cap nut if not using a second hand.
Very helpful staff thanks everyone.
Need a set of hands for a Hermle clockworks. Hour hand is 4 1/4″. Please recommend.
Hi,
Hermle quartz unit or a Hermle mechanical clock movement?
James Stoudenmire
30yr Clockmaker
Author of Clockworks.com
Quartz- battery operated
For Time Only movements (No chime, No pendulum) See this link
https://clockworks.com/clock-movement/quartz-clock-movements-time-only.html
For High Torque movements that are time only (No chime, No pendulum) See this link
https://clockworks.com/clock-movement/high-torque-quartz-clock-movements.html
For Chime Movements or Pendulum Movement See this link
https://clockworks.com/clock-movement/quartz-specialty-clock-movements.html
– James Stoudenmire 30yr Clockmaker Author of Clockworks.com
All I need is a set of hands where the hour hand is 4 1/4″. The minute hand has mysteriously disappeared. This model of clockworks is kind of fiddley to reset so I need both sets of hands back in place. Had to replace the batteries recently and resetting the time isn’t as simple as most quartz works.
Hi,
These are are the quartz clock hands we have to offer
https://www.clockworks.com/battery-quartz-clock-hands.html
James Stoudenmire
30yr Clockmaker
Author of Clockworks.com
