Mechanical Clock Parts InformationAbout mechanical hand nutsAbout clicks and click springs
Mechanical clock parts information and important facts to know. Additionally, it is not always easy to get parts for an antique clock. Many of the parts are now obsolete and the older the clock the harder things are to find.
Subsequently, it is not uncommon to need a part custom made. If that's the case, we may be able to help. Please email pictures of the movement to us here at Clockworks.
Mechanical clock hand nuts
One of the most common parts a Mechanical clock needs is the hand nut. As we said before, the older the clock the harder things are to find. So, the hand nuts Clockworks offer are for movements made after the 1930's.
Prior to 1930 clock hand nuts
There were not many standards on what the hand nut size should be on the early clocks. However, prior to around 1930 there is no telling what will work. In other words, it is literally trial and error. There was no standard hand nut size.
Insert the taper pin into the hole in the end of the minute hand arbor to secure the washer and minute hand to the clock. A taper pin is a small brass or steel rod that is wide on one end and skinny on the other. Clockworks offers them in an assortment of 100 to ensure the right one is there.
Clicks keep it wound in only one direction. Both have a ratcheting function as in a wheel being able to turn one way only. It spins one way and makes a clicking sound when this is done. That clicking sound is the click. This is the small part that makes the wheel turn in only one direction.
The click is held in the down position with some pressure from what is known as a click spring.
Clicks on spring driven movements
Often when a mainspring breaks the click will loosen considerably from the shock.
Replace or tighten the loose click to ensure it will not let go when winding the clock with the key.
It is not uncommon to think the mainspring broke when really the click eventually came loose and let the mainspring slip. Once the click on the ratchet slips the mainspring lets loose and momentum of it unwinding is unstoppable.
Clicks on weight driven movements
In general, this is a harder style to replace and not really available on the market. If you need these for a weight driven ratchet wheel it is best to replace the entire wheel. Replacing the entire wheel will include the ratchet wheel, the arbor it is on and also the gear.
It will have the click and spring on it all as one unit. This maybe the ratchet wheel on a chain driven clock or a cable drum for a cable driven clock. In both situations it is best to replace the entire component with the click and spring together. That way is it complete and done the best and quickest way.
Here are some various mechanical clock parts to help with clock repair. This clock parts page is basically the mix hardware that is sometimes needed. For parts to a pendulum please see This Page instead.
For clock hands, see the clock hands page. The most popular items on this clock parts page would be the German hand nuts and the taper pins. If you order glass be sure to get the correct size as these are returned and swapped often.
Mechanical Clock Parts
We have far more Mechanical Clock Parts then what is displayed here, please use the search bar up top of the page for more. Offering a full line of Hermle clock parts and components as well.
This is the most common suspension spring in use by far. Suspension A1 is for mantle clocks whereas A2 is for wall and grandmother units. The suspension A3 is for larger floor clocks such as a grandfather clock.
Brass top Clock Weight Hook Kit for modern German clock movements such as Hermle / Urgos / Kieninger. The top hooks are made with external threads or internal threads and also M4 threads or M5 threads.
German clock hand nuts for post 1950 clock movements. Fits Hermle, Kieninger, Urgos, Jauch and more. However these hand nuts will not work on a cuckoo clock. Therefore, Cuckoo clock hand nuts are available on the cuckoo parts page.
Round convex clock glass gets measured from one side to the other, the overall width. When working with a clock bezel it is important to order the right sized clock glass. If the glass is too narrow it will fall out the front of the bezel.
Suspension springs for some styles of Urgos floor clock movements. The square grandmother clock size movement may take the smaller size spring. Whereas, the rectangle grandfather movements take the larger size. However, these are not the only styles for Urgos movements.
The chime hammers are the clock parts that strike the chime rods. These hammers come in three sizes which are the approximate length of the hammer from the tip to the screw and are available in nylon or leather. Also available are just the tips themselves in nylon.
Frequently needed pendulum suspension spring rods in 17 inch lengths. These suspension rods are cut, bent, and modified as needed for the pendulum to hang onto the clock. They replace the pendulum suspension rods that have worn out and has the spring steel broken.
Hook and ring set for chain driven floor clock models. The chain link only consists of a bent wire that loops around to itself. Only needs two needle nose pliers to open the connecting point on the link and install these pieces.
Installation of the cuckoo chain hook and ring set is easy. Each link on the chain is only a wire folded into a unsoldered loop only. With two needle nose pliers a simple twist is all that is is needed to open the link.
Used in clock repair these tapered pins come in an assortment of 100 sizes and diameters. These Clock Parts have many uses in clock repair. For example, they attach some dials, movement plates, suspensions and sometimes hands on the clock.
Cuckoo hand nut repair kit, includes minute hand bushing, large nut and small nut. The large or small both will work, its only a matter of what looks best. These will fit most post 1950 mechanical cuckoo clocks of German origin.
