Hansen-Electric Clock Motor A-43RA

Hansen Synchron Motor to replace bad units. 1RPM, 60hz. Complete with a 10 tooth pinion. This unit’s pinion rotates to the right, clockwise. 110 Volt 60 Cycle.

Read more »

In stock

EL2: $160.00
Replacement Electric Clock Motor Movements - We offer these units that fit some street clocks or industrial applications. Hansen units being the most common.
Replacement Electric Clock Motor MovementsHow they are soldThe Obsolete IssueMechanical Substitutes

Please view these information tabs to learn about Replacement Electric Clock Motor Movements.

Electric clock motor description

None of the electric clock motors come with hands or hardware. This is due to them becoming harder to come by. So the electric clock motor description of the ones available are below.

Likewise, all of these units are meant as replacements for existing movements that are worn out or broken. Consider using a battery movement if building a new clock. The most popular electric movement is the Hansen electric motor.

These come in either bottom or rear time set. Often, these were popular with industrial and commercial applications as well as street clocks. In addition, the product description will explain how to get the proper hand shaft length on these units.

Antique electric clocks motor with wooden cases

In the early 80's there were electric mantle clocks with wooden cases. Unfortunately there is no hope for these units. They are no longer in production, however there may be alternate movement ideas available. This description is in another section and could save the clock from the town dump.

Electric clock motor hands

If you need hands, it may be necessary to modify some long quartz hands to fit it.

Modifications can be done to make them fit the electric unit. This is done by filing the minute hand hole. The electric movement hands are hard to come by and usually not available.

An electric clock hand solution

It is pretty easy to modify high torque quartz movement hands to fit. They have proven to work fairly well on the Hansen electric clock motors. So, simply file the minute hand hole with a needle file.

This will allow it to fit on the hand shaft of the Hansen unit. Of course, the hour hand will fit fine as this is a friction fit. In fact, just push the hour hand down onto the handshaft as far as it will go without touching the face of the clock.

The content of this website is copyright by Clockworks and written by James Stoudenmire in year 2022

The obsolete antique electric clock

In the 1920's through the 1950's there were many mechanical clocks that had an electric motor to run them.

Unfortunately most of those wonderful electro-mechanical shelf clocks have parts that are no longer available. Some of those units were very impressive, combining the electrical motor with a quality brass movement. This then eliminates the requirement of winding the clock for it to function.

Pending doom to the electric clock

If you need an obsolete antique motor, all one can do is throw the clock in the trash usually. However, it maybe possible to find someone to rebuild the coil if that is the issue.

We at clockworks.com do not perform such service however. We found it is often unsuccessful and would need to charge way to much for this to happen. In the end the clock would still be left with a motor that is old and worn. This is found not to be a viable long term solution and ultimately a waist of money.

Alternate units for the obsolete

There are alternate units one may consider if stuck on keeping the clock case. Options include a new wind up movement or switching to a movement that is run by a battery instead. These conversions have a further explanation in more detail in another section.

Quartz units require the center hole of the clock dial to be 3/8 wide. Drilling the 3/8 wide hole in the clock dial may have to be done because many of the electric units have a smaller size hole.

Quartz units have a 5/16 wide post to go through that 3/8 wide dial hole. It is a challenge to convert to a quartz unit, and not always successful. The electric clock movement that is now obsolete can have a replacement with a quality mechanical unit instead.

The obsolete antique electric clock - Conclusion

In conclusion, if you are going with a quartz replacement please know the project can go south. An error in drilling the dial out for example could render the dial useless.

The clock dial is unobtainable so the project is ditched. Left with a wood case with nothing to do. Sad story but it is what it is maybe best to just buy a new clock if it gets to that point.

For a functioning clock and stay high quality a mechanical unit is best. The mechanical unit would not require the drilling out of the clock dial. It will mount to the wood case and be a back wind instead of plugging into the wall.

The content of this website is copyright by Clockworks and written by James Stoudenmire in year 2022

Electric Clock - Mechanical Substitutes

All of the antique clock movements that are electric and have a wood clock case are obsolete. They are no longer available and not worth repairing. Parts are not available, the movement is useless and the clock looks like its heading for the dump. Such as shame when the clock is part of the family history.

There is something that can be done in this situation. Putting a quality mechanical unit as a substitute in the clock case could save the clock and have it running again. It would be a wind up mechanical unit and it will run 8 days every time its fully wound up. The clock will be functioning again and with a high quality movement.

Nice substitutes for the electric clock

The 8 day wind up Hermle 130-678 or 130-627 can be easily mounted in most tambour style clock cases. These are good substitutes to replace an obsolete electric motor clock movement.

Having a back wind mechanical unit such as one of these, there are no concerns with drilling holes in the clock dial to wind it up. Now lets look at some mechanical substitutes for the obsolete electric clock movements.

The Hermle 130-678 clock movement

The 130-678 unit is a bell strike unit that comes with the bells on it. 130-678 is the easiest unit to adapt to a clock case that contained an obsolete electric clock movement. This unit mounts to the wooden clock case with some wood screws only. Needs with it >new handsthis link

  • The winders are on the back, no dial holes to drill out
  • No chimeblock to mount because the movement comes with bells on it
  • Compact movement fits into the tightest of places

The Hermle 130-627 clock movement

The 130-627 unit is a bottom 3 hammer strike, so if the current electric movement has three rods below, this will work with it. If anything other than this as far as the strike goes, it would need to also get the chime block with the movement.

This unit will take chime block style A with 3 rods and most likely 7 inch length. The length of the rods does not matter so much, just the longer the rod the deeper the tone. This also needs new hands for the new movement. any of the German mechanical clock hands will fit.

Hermle Clock Movement 131 Series

130-678

  • Balance Escapement
  • 2 Bells back
  • 8 Day Wind Up
  • Back Wind
Front Side Side Back View Product
Hermle Clock Movement 131 Series

130-627

  • Balance Escapement
  • 3 Hammer Below
  • Bim Bam Strike
  • Back Wind
Front Side Back View Product
The content of this website is copyright by Clockworks and written by James Stoudenmire in year 2022

Hansen-Electric Clock Motor A-43RA

Hansen Synchron Motor to replace bad units. 1RPM, 60hz. Complete with a 10 tooth pinion. This unit's pinion rotates to the right, clockwise. 110 Volt 60 Cycle.

Additional information

Weight1 lbs
Dimensions2 × 2 × 2 in

8
Ask a Clock Question

Subscribe
Notify of
guest

oldest
newest most voted
Inline Feedbacks
View all comments
Bruce Benton
Bruce Benton
2 years ago

I have a Burpee Planting time clock made in the mid-70’s. It is not a particularly valuable clock but after 40 some years on our kitchen wall it has a lot of history with us. Recently it made a squalling noise and stopped. I took it apart expecting that a lady bug or some such had jammed the clockwork. No such luck. Fortunately when I purchased the clock I ordered a spare motor/movement assembly and swapped it out. Worked fine after I dissolved all of the dried up grease on the new motor shaft and got it freed up except now it makes a slight ticking sound as it runs. I don’t know if it is the motor or the movement. I suspect the motor as the ticking rate is about 4 per second. I don’t think it was anything I did with the reassembly. Maybe the ticking will stop or diminish with time. It is irritating to me only because I don’t know if the ticking is a symptom of a larger problem that will result in a premature failure. Question is will it go away with use or is it heading for a crash. Some insight please.

Bruce Benton
Bruce Benton
2 years ago
Reply to  Bruce Benton

I looked again at my Burpee clock trying to understand the source of the ticking sound. When I removed the M004 motor from the gear work and applied power it does not make a ticking sound…just a hum. The clockwork, once I removed the old hardened grease, is ridiculously free wheeling…probably to reduce as much friction as possible in order for the little motor to pull the chain that turns the moon phase and the calendar wheels. (A quartz movement would not be able to do that.) When I reattached the motor to the gear work, I started getting the ticking sound again. Apparently the vibration of the motor is being transferred to the free wheeling gear work resulting in a slight rattling of the gears. I applied grease to the various gears and it all quieted down. The original manufacturer must have applied grease for the same reason and it just hardened over time. So, the rattle or ticking sound can be addressed somewhat with a lubricant thicker than oil applied to the gears themselves. But a slight noise is always going to be there as it is inherent in the design.

Vincent Tarantino
Vincent Tarantino
2 years ago

I have a Seth Thomas electric clock that is no longer working. Can I get a replacement electric mechanism for it. 60C 115v

justin
justin
2 years ago

is this the replcement motor used in the burpee seed clock

Bruce Benton
Bruce Benton
2 years ago
Reply to  justin

I guess this is how to reply. The replacement motor/movement had an issue with the gear work movement. The motor worked just fine. I had it apart so many times, I wore out the main hand driver which is plastic and I had to pry off the star washer every time I took it apart. I may need to buy another movement since it still acts up and I need a new driver that is turned by the movement. Easier to show than explain with words. Thanks for following up. Don’t think you can help. Sorry.
