1161-853 Hermle Clock Movement

September 19, 2018 3:35 pm Published by Leave your thoughts

$458.00$488.00

The Hermle 1161-853 is a Triple Chime unit with 12 hammers on the back.

This high quality German movement comes pre oiled and includes its cables, pulleys, leader, suspension spring and hand nut.

Removal of this movement is easy and we provide instructions for the installation. This movement is in stock and can ship today. We are full time clock makers and retailers both, so if you need any assistance with install we can help.

Replacing a movement is less costly than a overhaul. These movements last 25 years before needing an over haul, but since its still being made at a fair price it is so much better just to replace. The clock will be problem free right away instead of months, last longer than a overhaul and its prelubricated.

Clear
1161-853: $458.00$488.00
1161 Hermle Clock MovementMVT NotesHermle IdentificationWhat Happened?Other Names UsedWhy get a new Hermle?

Please view these information tabs to learn about the movement 1161-853 and other 1161 Hermle Clock Movement units

1161 Hermle Clock Movement Notes

The 1161 Hermle Clock Movement Notes is written for information about the clock you own. These movements are great that is why there is so many made. They work night and day for 30 years without much complaint. So here is some information on these fine German made units.

Names on the Movement

The name maybe a number of makers on the movement, but it was made by Hermle not them. It may say Howard Miller, or Ridgeway, or Sligh, or many other names. If the number on the clock movement starts with 1161- its really made by the Hermle company. They let these companies to have there name on the movement instead of Hermle.

Chain or Cable Drive

This movement was made in both cable driven and also chain driven styles. The 1161-853 is the most popular and the most produced Grandfather clock movement in the world. When ordering a new movement it will come with the chains or cables with the pulleys.

Hermle movement 1161-853 Clock Weights

This clock movement takes three clock weights to run. The weights should be close to 8 or 10lbs, and does not have to be exact. Even though it does not have to be the exact weight, here is the exact weight specification from the factory. If the pendulum bob is less than 8 1/2 inches wide, it will take two at 7.7LBS and one at 9.9LBS. If the pendulum bob is 8 1/2 inches in diameter or larger, it takes two weights at 9.9LBS and one at 7.7LBS. Often they will have a 10 1/2 inch bob with the two at 7.7 and one at 9.9 and the customer says it ran 30 years like that.

Weight Placement

The placement for the clock weights on this series is the following. The heavy weight will go on your right as you face the clock if one heavy and two light. If you have two heavy weights and one light weight, the light one will go on your left as you face the clock. So what this means is the middle time train weight is variable light or heavy depending on pendulum bob diameter.

1161 Hermle Clock Movement Songs

This is a triple chime unit that plays out a melody on the quarter hours and then on the top of the hour it will strike out whatever times the hour is. The songs this one plays are your choice of the following. Westminster, Saint Micheal, or Wittington and also a silent option. For an additional cost is it able to have an auto night shut off switch (ANSO), this will make the clock quiet from 10pm to 7am on its own without your intervention.

The Support

Please note the factory will give you three years for the warranty. However we are clock makers here at Clockworks.com and we have been doing this sort of thing for a long time in this family (over 100 years of experience). If you have some sort of question or concern in whatever amount of time, we are not going to turn you down in response, we answer whatever questions you have even a decade later, it really does not matter. We take care of our customers in whatever way we can. The movement comes with instructions and any questions beyond the instructions can be emailed, chatted, or called in.

- - The content of this web page and web site was written and copyright by James Stoudenmire of Clockworks.com - It may not be used commercially without permission. - -

Hermle Clock Movement Identification

Identification of a Hermle clock movement is by locating the numbers on the back plate of the movement itself. It will not be in the manual that came with the clock or on the wood case. On the back plate of the clock movement there are numbers such as 451-050 94 cm. These numbers indicate everything there is to know about that particular mechanical clock movement.

Identification is the first step

In order to purchase a new movement, the old number has to match up with the new one. The new movement will be exactly the same. It is not a knock off. All of the existing clock components will fit the new movement. Proper identification is important when troubleshooting, ordering parts, or discussing compatible components. Thus, when contacting us it is imperative to correctly reference the number on the backplate of the movement.

A new Hermle clock movement is best

As discussed in several sections, a new movement is always best. A new unit is a fraction of the price of an overhaul. The clock will be up and running much faster than waiting months for an overhaul to be completed. The movement will last another 30 years. This is not possible with a restored unit.

- - The content of this web page and web site was written and copyright by James Stoudenmire of Clockworks.com - It may not be used commercially without permission. - -

Mechanical Clock Movement Wear

Mechanical clock movement wear after years go by because the oil turns solid. With age, the mechanical clock movement's oil solidifies and becomes black and sticky. By the time 20 or 30 years go by, the oil has solidified and is creating wear on the movements brass plates.

What wear and where

If you look at your old clock movement, you will see holes in the brass plates where there are small pivot arbors sticking into these holes. These pivots are what the gears of the clock ride upon and as the pivots spin in the solidified oil, this makes the holes oblong instead of round. With the pivot holes oblong, the holes are pinching the pivots and creating resistance in the gear train. With the solidified oil and the pinched pivots, the clock will eventually stop working or chiming.

Invisible clock movement wear

This wear takes place in the holes that are in the brass plates and is hard to identify sometimes. These holes in the brass plates become oblong instead of round and this pinches the pivot arbor going into it. Between this, and the solid oil, the clock ceases to function. To have this repaired is an expensive and long process. To have a mechanical movement serviced can cost two times as much or even three times the amount of the new one.

- - The content of this web page and web site was written and copyright by James Stoudenmire of Clockworks.com - It may not be used commercially without permission. - -

Hermle Clock Movement Aliases

Hermle produced clock movements and used aliases for names in a way. The movement could be stamped many names but really it will be made by Hermle. Some companies bought so many they were able to get there name on the movement instead of Hermle. The following is only a partial list of names that could be on the clock movement.

The best disguised Aliases

Seth Thomas also Mason and Sullivan had not only there name, also there own internal numbering system. This was stamped on the movement, instead of the Hermle number. Since it is not a Hermle number, the number would need to be converted to what the real number is . This is done with the Mason and Sullivan chart, or the Seth Thomas conversion Chart. However the Seth Thomas chart is not very accurate, please see instructions on that page.

Best to replace the movement

It is best to replace the clock movement if either of these names are on the movement automatically. You do not have to think and decide if repair is better, the answer is a simple no. These companies went out of business long ago and the unit is over its lifetime. The lifetime is 25 - 30 years before it needs an overhaul or replacement. Both ST and Mason Sullivan on the movement would indicate the clock is about 40 years old.

The other Hermle Clock Movement Aliases are easy

Hermle Clock Movement Aliases on other clocks used only their name, and not there own internal numbering system on the Hermle movements. So basically if the clock is of post war German origin you can just look at the number and forget the name. The numbers will indicate what movement it is. If it is a Hermle movement its 3 or 4 digits followed by a hyphen, and then 3 more digits. Like this 1161-853 or 340-020 or 351-060. If the numbers look like this it is made by Hermle.

Other Names Used

  • Hamilton
  • S. Larose
  • Mason & Sullivan
  • Welby
  • Pearl
  • Tally Industries
  • Bulova
  • Seth Thomas
  • Howard Miller
  • Sligh

Hermle Number Examples

Below are some typical examples of the Hermle clock movement numbering system. If your clock numbers are similar to this, its made by Hermle.

  • 451-050 94cm
  • 340-020
  • 140-070
  • 451-030 66cm
  • 341-020 45cm
  • 1151-050 114cm
  • 451-053 94cm
  • 1161-853 114cm
  • 141-070 45cm
  • 351-050 55cm
  • 1161-850 94cm
  • 241-070 94cm

- - The content of this web page and web site was written and copyright by James Stoudenmire of Clockworks.com - It may not be used commercially without permission. - -

New Clock Movement Benefits

New clock movement benefits far outweigh the benefits of an overhaul. This section will explain why that is and what the best course of action is to get your clock working.

Getting the movement worked on

Clocks need to be oiled after 10 years or so. Then, after 20 or 30 years, a full break down of the movement is necessary. This is all well and good and can be done with the old movement. The movement will run for another 5 or 15 years with no issues but then it will be time to do it again.

Every time the movement is worked on and re-bushed, it will last less and less time before it needs attention again. The repair process is expensive because it takes time to separate the plates, remove all the gears, do the necessary work, and then put them all back together again. This process may need to be redone if not perfect the first time. The turn around time to complete an overhaul could be anywhere from 1 to 3 months, and in some extreme cases, a year. It is a slow moving venture that costs twice as much as a new movement would. If a new movement is not available, then this is the best, and only, way to handle a clock repair.

Replacing with a new clock movement

If the movement is still in production, it is far better to just get the new one. Mass production makes the movement so affordable it will cost a fraction of the price of the repair work. The movement will be the same one but brand new and ready to run 30 years without much complaint. There is absolutely no way to repair an old movement so that it is better than new. Even the best clockmaker using the best equipment cannot make the movement better than a new one.

A new one is a factory fresh restart. The clock will be like it was originally when it was purchased from the store. The new movement will be made by the same people, with the same machines, and the movement is the same. It is not a close replica or made somewhere else besides Germany. It is the same movement. Not a knock off or replica. So wouldn't it make sense to get the new one instead of chasing the old? The choice is clear and obvious. The new movement will cost a fraction of the price and the clock is up and running in no time.

Movements to consider getting repaired instead

If a unit is no longer in production and not available new, then a repair is most likely your only option. However we will try to convert it to a new unit that is close and easy to adapt. If it is not an easy one to adapt, or would take too much case work, then the best solution is to get it worked on.

Another movement to consider getting overhauled instead of replaced is the tubular bell, which is a high end movement. The price of a tubular bell unit makes an overhaul more attractive. This is because of the high price on the new ones which is currently around $1600. Usually the price is less for the new unit but instead these units are more costly than the overhaul by clockworks.com anyway. We can charge only $900 for the complete overhaul on these units. Ultimately the choice is yours. There is a good argument in both directions that makes sense on these expensive units.

Clockworks.com = The best repair service

We would love to do the overhaul here at clockworks.com and we do the best job. There are two ways to fix clocks; the easy way and the hard way. We only do it the hard way with no short cuts. It is even more important for us to do your repair than another company because we do not go to your house. There is no one being intrusive in your home and possibly damaging your clock case.

The movement itself is the only item that gets sent to us. No components need to be sent since we have everything else here such as weights, dials and pendulums. It is a great advantage to have clockworks.com work on your movement for this fact alone. A clock supply depot such as us does not need to wait for parts. We possess everything we could possibly need to complete a thorough, professional clock repair right here.

The new movement

New clock movement benefits usually do indeed outweigh the repair option. The movement will already come lubricated with clock oil so there is no need to oil it. The clock comes with cables and pulleys, or chains, the leader, and suspension spring. This is everything that comes out when you remove the two screws that are under the movement, besides the dial and weights.

Once you get the hands and the clock dial out of the way (instructions included) it's only a matter of removing the two screws from underneath. The new movement can be swapped out by an experienced person in 10 or 15 minutes. An inexperienced person will take longer, but the point is that it isn't hard to do. There are some instances where a clock case was made in an annoying way that makes it more difficult, but for mass produced clocks this is not the situation. This more related to a few individual clockmakers who may have designed the case to make it more tricky to get the movement in or out.

Summary

A new clock movement is typically less than half the cost of an overhaul. It will also be on its way to the customer instantly instead of months later. A new clock movement will last the longest of any other choice.

- - The content of this web page and web site was written and copyright by James Stoudenmire of Clockworks.com - It may not be used commercially without permission. - -

Hermle Clock Movement

The numbers on the back plate of the 1161 Hermle Clock Movement is everything one needs to get a replacement. If the numbers match then the 1161 Hermle Clock Movement matches. Please sure to select the proper CM length that matches the old unit.


Hermle Clock Movement
Assistance = 800-381-7458

  • Brand New and Original
  • Plate size 120 x 120mm
  • Chain or Cable Driven
  • Triple Chime
  • 1161 Hermle Clock Movement
1161 Hermle Clock Movement
  • A fraction of the price of an overhaul
  • Should last 25-30 years, an overhaul would not
  • Instructions and expert support
  • Hermle Clock Movement of Germany

1161-853 Hermle Clock Movement

1161-853 Hermle Clock Movement is a triple chime chain or cable driven unit with three weights. This is a rectangle shaped movement with the movement plate size of 140 x 200mm and takes a size #8 crank (If cable).

What is being offered on this page is the movement only with out the pendulum, gong or dial. This high quality German movement comes oiled and includes its leader, suspension spring and hand nut.

Ordering a Hermle Clock Movement

The numbers off of the back plate of the movement itself are needed when ordering a Hermle clock movement. The numbers are matched up so the new movement will be exactly the same as the old one. Replacing the movement is a fraction of the price of a repair. It is also the fastest way to get the clock up and running again.

Clock movement removal and installation

Removing and installing the clock movement requires the most basic tools. If you can change the spark plug on your lawn mower, this will be a breeze. All of the Hermle clock movements are in stock and ship immediately. We are full time clock makers and retailers. This means we can help you from start to finish. If you need assistance in picking out the correct Hermle clock movement, installation or troubleshooting, we can help. Please do not hesitate to ask.

Matching the CM when ordering

This note only applies if your Hermle clock movement has a pendulum. You will need to match up the CM length from the back plate of your old unit to the new one. The options in the drop down menu ultimately indicate stock items that are available. However, if there is a CM number you need that is not listed, we can usually create it by changing some gears. If this is the situation please give us a call 800 381 7458. There is an extra fee for regearing the movement. Usually this is an additional fee of $30 to $40.

Conclusion

Replacing a movement is less costly than an overhaul. The movement will last another 25 years before needing any work. Since it is still in production, and offered at a very reasonable price, it makes sense to replace the movement. The clock will be problem free right away, instead of months. Plus it will inevitably last longer than an overhaul. There is no way you can get better than brand new. So please make the wise decision of replacing whenever possible.

Hermle Clock Movement Directory Explanation

Hermle Clock Movement Directory is to get to the correct page that contains your clock movement. The Hermle mechanical movements have numbers on the back plate starting with the below few numbers, and then followed by a - dash and then some more numbers. Examples = 340-020 131-070 1161-853 351-020 and similar. So if your clock says something like 1161-053 you would drop the second half and click the 1161 button below. This will bring you to the page where 1161-053 and the rest of the 1161 series resides.

Hermle Clock Movement Directory

HermleHermle Clock Movement Directory, Number starts with.....

Mechanical Clock Movement Identification by Clockworks.com
Hermle Clock Movements
Mechanical Clock Movement Identification by Clockworks.com

If Not Listed

If your Hermle movement is not found on these pages we may still have it as a conversion or we maybe able to create it out of what exists. Please email your movement number or a picture of the back plate to [email protected] If your movement numbers do not look like the Hermle movement numbers as described it maybe made by someone else. The mechanical movement identification page will assist you with determining who made the clock. This is for post WW2 modern mechanical clock movements made in Germany only however.

Additional information

Weight 6 lbs
CM Length

94cm, 100cm, 114cm, 94cm ANSO, 114cm ANSO
